Cool if I understand only some of things that you have said. So you have a beginner guide I could follow?

I would not publicly expose ssh. Your home IP will get scanned all the time and external machines will try to connect to your ssh port.

Also run the reverse proxy on a dedicated box for it in the DMZ

Who are you using for your domain? I was told if I used cloudfair they would ban me for having streaming traffic over their DNS.

I’m fidgeting with Tailscale but I find this solution some what lacking

I’m fidgeting with Tailscale right now, only to stream on a AppleTV at a friend house. So far no luck but that’s not me that set up Infuse, so could be an operator error on my friend part

I’m using Tailscale right now but so far no luck on my friend AppleTV. But like I said elsewhere it’s probably a operator error

I’ll try looking into that

Look pretty interesting. Do you have guide I could follow ?

I kept the main domain open, but redirected it to a rickroll

How are you geoblocking?

I’m looking into it but I find that starting (or keeping open) Tailscale for music is not the best system.

I’m looking into building a shared Jellyfin library between friends

Is the funnel URL accessible by everyone who knows it? I.e what are the chances someone finds the URL and gets access to it?

That’s probably this type of setup I would want but I miss the technical know how, so if you have a cool beginner guide

What’s the point of authentik when Jellyfin already has authentication?

This is 99% my setup, just with a traefik container attached to my wifeguard container.

Can recommend especially because I can move apartments any time, not care about CGNAT (my current situation which I predicted would be the case), and easily switch to any backup by sticking my boxes on any network with DHCP that can reach the Internet (like a 4G hotspot or a nanobeam pointed at a public wifi down the road) in a pinch without reconfiguring anything.

Is Nginx Proxy Manager running on the VPS itself and then the proxy routes across the wireguard to your home server? Or is the VPS just port forwarding to your home server which runs the proxy?

I was just trying to get a setup like this going yesterday. I used standard Wiregaurd and got that working between the VPS and home server, but I was trying to set up Caddy as a reverse proxy to direct the incoming traffic through the WG VPN to my services. I wasnt able to figure it out yesterday. Everyone online says Caddy is so simple, but I’m such a noob I just have no idea what it’s doing or how to troubleshoot.

That’s my feeling too

Someone mentioned above that cloudflare will ban you for streaming through their tunnel. Just be warned.

Imo that’s perfectly fine and not idiotic if you have a static IP, no ISP blocked ports / don’t care about using alt ports, and don’t mind people who find your domain knowing your IP.

I did basically that when I had a fiber line but then I added a local haproxy in front to handle additional subdomains. I feel like people gravitate towards recommending that because it works regardless of the answers to the other questions, even their security tolerance if recommending access only over VPN.

I have CGNAT now so reverse proxy in the cloud is my only option, but at least I’m free to reconfigure my LAN or uproot everything and plant it on any other LAN and it’ll all be fine.

Reverse proxies can be useful for hiding your IP if you do something like host it in a VPS and tunnel the traffic back to your self hosted service. There’s also a lot of documentation on attaching things like fail2ban or crowd sec which can be helpful in reducing the threat from attacks. if you’re running lots of services it can reduce the risk of two apps using the same ports as ultimately everything will go through ports 80 and 443 on the public facing side. Finally again if you’re hosting several services having a central place to manage and deal with cert from can save a lot of time rather than having to wrangle it per service/ server.

I think the reason why its generally suggested to use a VPN is because it reduces the risk of intrusion to almost zero. Folks that are not network/sys admin savy would feel safer with the lowest risk solution. Using the port forward method, there could be configuration mistakes made which would unintentionally expose a different service or parts of their home network they don’t want exposed. And then there’s the possibility of application vulnerabilities which is less of an issue when only VPN users can access the application. That being said, I do expose some services via port forwarding but that’s only because I’m comfortable with ensuring its secure.

Reverse proxy is really useful when you have more than one service to expose to the internet because you only have to expose one port. It also automates the certificate creation & simplifies firewall rules inside the home network

Nah, setting non-standard ports is sound advice in security circles.

People misunderstand the “no security through obscurity” phrase. If you build security as a chain, where the chain is only as good as the weakest link, then it’s bad. But if you build security in layers, like a castle, then it can only help. It’s OK for a layer to be weak when there are other layers behind it.

Even better, non-standard ports will make 99% of threats go away. They automate scans that are just looking for anything they can break. If they don’t see the open ports, they move on. Won’t stop a determined attacker, of course, but that’s what other layers are for.

As long as there’s real security otherwise (TLS, good passwords, etc), it’s fine.

If anyone says “that’s a false sense of security”, ignore them. They’ve replaced thinking with a cliche.

It feels like everything is a tradeoff and I think a setup like this reduces the complexity for people you share with.

If you added fail2ban along with alert email/notifications you could have a chance to react if you were ever targeted for a brute force attempt. Jellyfin docs talk about setting this up for anyone interested.

Blocking IP segments based on geography of countries you don’t expect connections from adds the cost of a VPN for malicious actors in those areas.

Giving Jellyfin its own VLAN on your network could help limit exposure to your other services and devices if you experience a 0day or are otherwise compromised.

Anyone wanna yell at me for being an idiot and doing everything wrong?

Not yell, but: Jellyfin is dropping HTTPS support with a future update so you might want to read up on reverse proxies before then.

Additionally, you might want to check if Shodan has your Jellyfin instance listed: www.shodan.io

It’s difficult to say exactly what all a reverse proxy adds to the security conversation for a handful of reasons, so I won’t touch on that, but the realistic risk of exposing your jellyfin instance to the internet is about the same as handing your jellyfin api over to every stranger globally without giving them your user account or password and letting them do whatever they’d like for as long as they’d like. This means any undiscovered or unintentional vulnerability in the api implementation could easily allow for security bypass or full rce (remote code execution, real examples of this can be found by looking at the history of WordPress), but by siloing it behind a vpn you’re far far far more secure because the internet at large cannot access the apis even if there is a known vulnerability. I’m not saying exposing jellyfin to the raw web is so risky it shouldn’t be done, but don’t buy into the misconception that it’s even nearly as secure as running a vpn. They’re entirely different classes of security posture and it should be acknowledged that if you don’t have actual use for internet level access to jellyfin (external users, etc, etc) a vpn like tailscale or zero tier is 100% best practice.

If your reverse proxy only acknowledges jellyfin exists if the hostname is correct, you won’t get discovered by an IP scanner.

Mine’s on jellyfin.[domain].com and you get a completely different page if you hit it by IP address.

If it does get found, there’s also a fail2ban to rate-limit someone brute-forcing a login.

I’ve always exposed my home IP to the internet. Haven’t had an issue in the last 15 years. I’m running about 10 public-facing services including NTP and SMTP.

Exactly this !
